Gantry Type Drilling & Tapping Machine
14500 INR/Piece
Product Details:
- Table Size 1500 mm x 3000 mm
- Cutting Area 1500 mm x 3000 mm
- Dimension (L*W*H) 2500 mm x 2000 mm x 1700 mm
- Diameter Drilling Diameter: 3-16 mm
- Motor Power 3.5 kW (Spindle Motor)
- Noise Level 75 dB
- Condition New
- Click to View more
X
Gantry Type Drilling & Tapping Machine Price And Quantity
- 1 Piece
- 14500 INR/Piece
Gantry Type Drilling & Tapping Machine Product Specifications
- Gantry Type Drilling & Tapping Machine
- Red & White
- High-strength Steel Body with Heavy-Duty Aluminum Components
- 3.5 kW (Spindle Motor)
- Drilling Diameter: 3-16 mm
- 2500 mm x 2000 mm x 1700 mm
- Automatic
- CNC
- 1500 mm x 3000 mm
- 1500 mm x 3000 mm
- Electric
- Programmable CNC Controller
- Suitable for drilling, tapping, routing, engraving, and machining on metal, plastic, and composite materials for industrial manufacturing.
- Gantry Type CNC Drilling and Tapping
- Multi-Spindle Operation, Various Material Compatibility
- 50/60 Hz
- Heavy-duty frame, precise linear guideways, automatic tool changer, high-speed spindle, easy programming interface, reliable performance.
- 3.5 kW
- Yes
- 380V / 220V (Customizable)
- New
- 1800 kg
- 0-24000 rpm (Variable)
- 75 dB
- ISO30/ER32
- Touch Screen LCD Display
- 0.02 mm
- 8-12 Tools (Optional)
- G-Code, DXF, CAD/CAM Software Supported
- T-Slot / Vacuum Table Options
- Servo Motor with Ball Screw Transmission
- X: 1500 mm, Y: 3000 mm, Z: 300 mm
- Integrated Flood Coolant System
- Automatic Centralized Lubrication
- 8000 mm/min
- Fully Enclosed Electrical Cabinet with Overload & Short Circuit Protection
- Floor-mounted, Vibration Dampened Base
Gantry Type Drilling & Tapping Machine Trade Information
- 10 Piece Per Week
- 1 Days
Product Description
Gantry Type Drilling & Tapping Machine
Gantry Type Drilling & Tapping Machine is a smart computer controlled machining center which is used to make precision holes and highly finished threads inside the preexisting holes for the easy and smooth fastening of the mechanical fasteners such as tap screw and bolts. It is provided with a large machining bed over which a gantry is provided which gives longitudinal and transverse movement to the spindle mounted tool. It is provided with a separate electronic control unit to set operational parameters.
Robust Design & Precision Engineering
Built with a vibration-dampened base and a heavy-duty frame, this machine guarantees minimal operational vibration and maximum stability. The precise linear guideways and servo-driven ball screw transmission deliver repeatability accuracy of 0.02 mm, making it ideal for demanding applications in the manufacturing industry.
Advanced Automation & Control
Featuring a touch screen LCD interface and an automatic tool changer (8-12 tools optional), programming and operation are streamlined for efficiency. The fully enclosed electrical cabinet includes overload and short circuit protection, ensuring operator safety and long equipment lifespan.
Versatile Application & Material Compatibility
Capable of drilling diameters from 3 to 16 mm, this gantry CNC system handles drilling, tapping, routing, engraving, and other machining processes across various materials, making it highly versatile for metalworking, plastics, composites, and more. Multi-spindle operation and customizable tool sets cater to a wide array of industrial requirements.
FAQ's of Gantry Type Drilling & Tapping Machine:
Q: How does the gantry type drilling & tapping machine ensure high precision operations?
A: The machine relies on precise linear guideways, a vibration-dampened base, and a servo motor-driven ball screw transmission to achieve repeatability accuracy of 0.02 mm. This ensures dimensional consistency and high-quality results for every application.Q: What materials and workpiece sizes can this machine handle?
A: With a cutting area of 1500 mm x 3000 mm and a drilling diameter range of 3 to 16 mm, it efficiently processes metal, plastic, and composite materials. The sturdy table structure (T-slot or vacuum options) accommodates a wide variety of workpieces for industrial jobs.Q: Where is this CNC gantry machine commonly installed and used?
A: Designed for industrial manufacturing, the machine is typically floor-mounted in factories, workshops, or production facilities across sectors such as automotive, aerospace, metal fabrication, plastics, and general manufacturing.Q: What is the process for programming and operating the machine?
A: Operators use the touch screen LCD interface and compatible CAD/CAM software to program machining cycles. The CNC controller accepts G-Code and DXF files, streamlining setup for drilling, tapping, routing, or engraving tasks.Q: How does the automatic lubrication and coolant system benefit machine operation?
A: The integrated flood coolant and centralized automatic lubrication systems prolong tool life, enhance machining quality, and reduce maintenance needs by keeping components and workpieces cool and properly lubricated throughout production.Q: What safety features and protections are built into the machine?
A: The machine has a fully enclosed electrical cabinet with built-in overload and short circuit protection. These features offer safety for operators and additional security for the equipment's electrical system.Q: When should routine maintenance be performed on this CNC machine?
A: It is recommended to follow the manufacturer's maintenance schedule, including regular checks of the lubrication and coolant systems, cleaning filters, inspecting spindle and guideways, and verifying electrical protections to ensure optimal and safe operation.Tell us about your requirement
